SRM 255 XXL Series
Fully Automatic Fabric Spreading Machine
Technical Specifications
Available Operation Widths : 180 cm (different widths on request)
Maximum Roll Diameter : 65 cm
Maximum Fabric Roll Weight : 250 kg
Maximum Spreading Speed : 125 m/min
Maximum Spreading Height : 18 cm
Power Source : 380 V. 50 Hz, 3 kW
Features
Chino denim type is designed for spreading openwork fabrics
Denim/Jeans - Assembled for spreading the heavy type weaving fabric
Preferable language; Turkish or English
Remote connection (option)
Via intensive sensor, the ability to spread the beginning of the fabric in each ply in the some line automatic.(gain fabric)
Ability to interfere with the software and spread at fully automatic mode
Auto-Stop feature when the roll runs out or pre-recorded number of folds is achieved
Ability to unroll or rewind (for Roll Fed Fabrics)
Ability to enter different speed choices, in order to save time during idle turns
One way or zig-zag spreading features (zig-zag is optional)
Spreader system which ascends automatically, in accordance with spreading height
Backwards opening cradle and loading extension, enabling easy fabric loading
True-sense safe operation, ensured by privileged safety sensors
User friendly Touch Screen panel
